Die casting and automotive
Vision inspection from the press to machined surfaces.
One line, three inspections
From raw casting to finished surface.
-
01Leaving the press
Is the casting complete?

Mhira3D inspects the casting in the robot gripper after extraction. 3D imaging and thermography reveal different aspects of the same part.
- 01Completeness and deformation
- 02Thermal distribution
-
02After trimming
Is the trimmed part intact?
Anglerfish checks the integrity of the trimmed part before further machining.
Explore Anglerfish -
03After machining
Is the surface acceptable?
Magpie examines machined surfaces against acceptance criteria defined for the component.
Explore Magpie
The complete cycle
From the press to the machined surface.
“A reliable partner for our foundries.”
Former head of Idra Group, Ferrario draws on experience with the group’s foundries to explain what Imago brings: vision, automation and artificial intelligence, from casting inspection to a cell that adapts to each die change.
Die casting in practice
Three applications from our archive. Explore the cases to discover the parts and inspections developed.
All die-casting cases
Read the caseDie castings: hole, lever, edge and print integrity
Holes, levers, pins, edges and print on a complex casting, with checks for burrs, cracks and breaks.
Read the caseMachined surfaces: porosity and integrity near edges
Porosity, pore concentrations, edge integrity and obstructions on machined surfaces and in internal casting areas.
Read the casePulleys: surfaces, edges and recess geometry
Treated and grooved surfaces, edges, recess angles and distances between reference features on machined pulleys.
Which stage needs inspection?
Describe the part, the defects to detect and the line conditions.
Describe your problem
